John Michael Antos

US Patent:

6827410, Dec 7, 2004

Filed:

Aug 22, 2002

Appl. No.:

10/225661

Inventors:

John M. Antos - Ann Arbor MI
James C. Butler - Sidney OH

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

A47F 304

US Classification:

312405, 312236

Abstract:

A door assembly for a refrigerator having a cabinet with a cabinet opening, a cabinet height and a cabinet width includes a main body portion and a cap portion. The main body portion has a door height and a door width generally corresponding in size to the cabinet height and the cabinet width, respectively. The cap portion is secured to and upwardly extends from the main body portion. The cap is configured to substantially cover a plurality of control elements upwardly extending from the cabinet when the door assembly is articulated to a closed position.

US Patent:

7097213, Aug 29, 2006

Filed:

Oct 21, 2002

Appl. No.:

10/493359

Inventors:

John M Antos - Ann Arbor MI, US
James C Butler - Sidney OH, US

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

E05C 17/04

US Classification:

292 56, 292278, 292 11, 292 29, 292DIG 71, 312401, 62440

Abstract:

A latching arrangement for a refrigerator door includes a striker unit, a first latch arm and a second latch arm. The striker unit is secured to a cabinet of the refrigerator. The first latch arm is interconnected to the door for pivotal movement about a generally horizontal axis between a latched position and an unlatched position. In the latched position, the first arm releasably engages a first striker portion of the striker unit. The second latch arm is interconnected to the door for pivotal movement about a generally vertical axis between a latched position and an unlatched position. In the latched position, the second latch arm releasably engages a second striker portion of the striker unit.

US Patent:

7350886, Apr 1, 2008

Filed:

Oct 21, 2002

Appl. No.:

10/493358

Inventors:

John M. Antos - Ann Arbor MI, US
Wilco Wessels - AE Ulvenhout, NL

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

A47B 88/00

US Classification:

312404

Abstract:

A refrigerator storage bin includes a main body portion and a cover. The main body portion defines a bin storage area. The cover selectively provides access to the bin storage area. The cover is pivotally attached to a sidewalk of a cabinet of the refrigerator for rotation about a pivot axis between an opened position and a closed position. The cover and main body portion include cooperating surfaces that articulate to cover from the closed position to the open position in response to translation of the main body portion from a first position to a second position.

US Patent:

7753461, Jul 13, 2010

Filed:

Oct 21, 2002

Appl. No.:

10/493357

Inventors:

David W. Leistner - Sidney OH, US
John M. Antos - Ann Arbor MI, US
James C. Butler - Sidney OH, US
John W. Wissinger - Gregory MI, US

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

A47B 96/04

US Classification:

312408, 312313, 211184, 108 27

Abstract:

A refrigerator shelving system includes an item retainer for securing items carried on a shelf, a mounting member for releasably securing a shelf to a cabinet of the refrigerator, and a spill tray carried by the shelf. The item retainer is movable between a first position and a second position such that when in the first position, a first side upwardly extends from the shelf and defines a fence and when in the second position the first side is parallel and adjacent to an upper surface of the shelf. The shelf mounting member includes a first portion rotatably interconnected to a lateral side of the shelf and a second portion for selectively engaging a horizontal slot of a cabinet of the refrigerator. The mounting member is rotatable from a first position to a second position to engage the second portion with the horizontal slot. The spill tray includes a main body portion and a plurality of mounting elements.

US Patent:

20050136822, Jun 23, 2005

Filed:

Oct 21, 2002

Appl. No.:

10/493375

Inventors:

John Antos - Ann Arbor MI, US
Alfard Jansen - Ek Den Haag, NL
David Leistner - Sidney OH, US

International Classification:

B60H001/00

US Classification:

454118000

Abstract:

The vent assembly () includes a vent frame (), a vent () and a retainer (). The ven frame attaches to a sidewall () of the vehicle. The vent frame defines an opening and includes a projection. The vent is received within the opening and is removably attached to the vent frame. The retainer selectively secures the vent to the vent frame. The retainer is slidably mounted on the vent and is translatable between an engaged position and a non-engaged position. In the engaged position, the vent is secured to the vent frame through engagement of the retainer with the projection of the vent frame. In the non-engaged position, the vent may be removed from the vent frame.

US Patent:

41457730, Mar 27, 1979

Filed:

Apr 3, 1978

Appl. No.:

5/892762

Inventors:

Frank T. Sargent - Ann Arbor MI
John M. Antos - Ann Arbor MI
Erin J. Lindsay - Ann Arbor MI

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

E03D 100

US Classification:

4321

Abstract:

Apparatus for venting a sealed holding tank of a portable toilet to equalize the atmosphere and tank pressures before opening and closing the inlet port of the holding tank, said holding tank including a valve assembly for opening and closing the inlet port of the tank, and a vent port means in the tank associated with the valve assembly so that when the valve assembly is moved toward its open position, the vent means will be opened immediately prior to opening of the inlet port and when the valve assembly is moved toward its closed position, the vent port will be closed immediately after closing of the inlet port.

US Patent:

50106023, Apr 30, 1991

Filed:

Jul 13, 1990

Appl. No.:

7/553353

Inventors:

Charles L. Sargent - Ann Arbor MI
John M. Antos - Ann Arbor MI
Scott I. Biba - Ann Arbor MI

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

E03D 1100

US Classification:

4432

Abstract:

A portable toilet having a battery operated flushing assembly that is powered by batteries carried in the toilet. The batteries provide for a "pulsed" flushing action of the flush water and this is achieved by the use of an axial flow pump which is operable to lift small amounts of water small distances to the bowl in a repeatable fashion. This facilitates flushing of the toilet, makes it easier for the user to flush the toilet, and provides for efficient and complete flushing. A selectively operable closure plate prevents leakage of water from the toilet bowl during transport of the toilet.

US Patent:

D3905250, Feb 10, 1998

Filed:

Apr 2, 1996

Appl. No.:

D/052467

Inventors:

John M. Antos - Ann Arbor MI
John R. Selina - Brighton MI
David B. Cameron - Brighton MI
James M. Byrne - Ann Arbor MI
Gerard Cornelis Rijn - Arend, NL
Marinus Antonius Ros - Havik, NL

Assignee:

Thetford Corporation - Ann Arbor MI

International Classification:

1216

US Classification:

D12196
