Paul L Kalmar

US Patent:

7578164, Aug 25, 2009

Filed:

Sep 22, 2005

Appl. No.:

11/232625

Inventors:

Graham David Sherlock - Greenville SC, US
Paul Lawrence Kalmar - Zirconia NC, US
Benjamin Erick Baker - Pelzer SC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

G01B 3/30

US Classification:

73 179, 738658, 33549, 415118

Abstract:

A method for inspecting a turbine nozzle segment includes positioning the turbine nozzle segment on a base of a tool, with the outer forward face and the inner forward face of the turbine nozzle segment contacting a surface of the base. The outer wall is positioned between a first pedestal outer stand and a second pedestal outer stand of the tool, and the inner wall is positioned between a first pedestal inner stand and a second pedestal inner stand of the tool. At least one of a position, a depth and a width of a seal slot formed in a side edge of the outer wall and/or the inner wall is measured. At least one axial dimension of the turbine nozzle segment and at least one radial dimension of the turbine nozzle segment are measured.

US Patent:

7735222, Jun 15, 2010

Filed:

Nov 30, 2005

Appl. No.:

11/290347

Inventors:

Graham David Sherlock - Greenville SC, US
Paul Lawrence Kalmar - Zirconia NC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

B23P 6/00

US Classification:

298891, 298897, 416115

Abstract:

A tool capable of removing material is applied to a turbine wheel cooling slot. Material is removed from a selected portion of the cooling slot with the tool. And, stress concentrations are reduced within the slot through the removal of material.

US Patent:

7735238, Jun 15, 2010

Filed:

Jul 31, 2008

Appl. No.:

12/183434

Inventors:

Graham David Sherlock - Greenville SC, US
Paul Lawrence Kalmar - Zirconia NC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

G01B 5/02

US Classification:

33832, 33833, 33810

Abstract:

A measuring tool measures a trailing edge position of gas turbine nozzle. The tool includes a frame member attachable to at least one predefined reference point on the nozzle. At least one sliding member is slidable relative to the frame member and includes a measuring point engageable with the trailing edge. A position of the sliding member relative to the frame member is determinative of the trailing edge position.

US Patent:

7762004, Jul 27, 2010

Filed:

Jan 25, 2008

Appl. No.:

12/010513

Inventors:

Graham D. Sherlock - Greenville SC, US
Paul L. Kalmar - Zirconia NC, US
Christopher E. Thompson - Danvers MA, US
Benjamin E. Baker - Simpsonville SC, US
Todd Moran - Greenville SC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

G01B 3/14

US Classification:

33562, 33645

Abstract:

An inspection tool for a turbine bucket shroud includes: a clamp device for clamping a dovetail portion of a turbine bucket; a template plate provided with an aperture defined by a edge shaped to conform to a specified shape of the turbine bucket shroud, wherein the template is moveable to a location over the turbine bucket shroud in a direction toward the clamp device, and wherein, at the location, the aperture represents a design specification location for the turbine bucket shroud relative to the dovetail portion of the bucket. A measurement gauge is provided for measuring gaps between edges of the shroud and edges of the template aperture.

US Patent:

7934302, May 3, 2011

Filed:

Feb 9, 2009

Appl. No.:

12/367830

Inventors:

Paul L. Kalmar - Zirconia NC, US
Graham D. Sherlock - Greenville SC, US
Francis E. Nimmons - Fayetteville OH, US
J. David Mays - Hamilton OH, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

B23Q 1/25

US Classification:

292811, 292835

Abstract:

An apparatus and method are provided for removing a blade from a dovetailed slot in a wheel of a rotating machine. At least one device is adapted to apply a pushing force on a first surface of a blade. A turntable for supporting the wheel has indexing capability to advance the wheel by a predetermined amount. The device can be used to remove one or more blades from the wheel.

US Patent:

8142161, Mar 27, 2012

Filed:

Sep 20, 2007

Appl. No.:

11/858186

Inventors:

Stephen Robert Prince - Simpsonville SC, US
Stephen Paul Wassynger - Simpsonville SC, US
Thomas R. Tipton - Greer SC, US
Tushar S. Desai - Bangalore, IN
Michael E. Friedman - Simpsonville SC, US
Christopher Robert Kelly - Easley SC, US
James Purdue Masso - Chesterfield VA, US
Paul L. Kalmar - Zirconia NC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

F01D 5/32

US Classification:

416221

Abstract:

A rotating assembly. The rotating assembly may include a wheel, a slot positioned about the wheel with the slot having a staking recess positioned therein, a wheel attachment positioned within the slot, and a staking insert positioned within the staking recess. The staking recess axially retains the staking insert and the wheel attachment radially retains the staking insert.

US Patent:

20070094880, May 3, 2007

Filed:

Oct 28, 2005

Appl. No.:

11/260151

Inventors:

Graham Sherlock - Greenville SC, US
Paul Kalmar - Zirconia NC, US
Christopher Thompson - Greenville SC, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

G01B 5/00

US Classification:

033542000

Abstract:

A tool for measuring seal slot position includes a tool shaft having a longitudinal axis, a pin eccentrically disposed at one end of the tool shaft relative to the longitudinal axis, and a disk member disposed at an opposite end of the tool shaft that facilitates rotation of the tool shaft and pin in the seal slot. The tool provides for increased accuracy in measuring seal slot position such as turbine nozzle seal slot position.

US Patent:

20070234549, Oct 11, 2007

Filed:

Mar 17, 2006

Appl. No.:

11/377217

Inventors:

Graham Sherlock - Greenville SC, US
Paul Kalmar - Zirconia NC, US
Roy Reinertsen - Mason OH, US

Assignee:

General Electric Company - Schenectady NY

International Classification:

B23Q 7/00

US Classification:

029559000

Abstract:

A manipulator assembly for supporting and manipulating a nozzle segment, for example of a gas turbine or a steam turbine. The assembly includes a vertical support member and a horizontal support member. The vertical support member is mounted for selective vertical displacement relative to a base and the horizontal support member is operatively coupled at a proximal end thereof to the vertical support member so as to be vertically displaced therewith and so as to be pivotable about a vertical axis of the vertical support member. A nozzle segment fixture is operatively coupled to a distal end of the horizontal support member for selectively supporting and manipulating a nozzle segment.
