Yufei Zhao

US Patent:

20200319734, Oct 8, 2020

Filed:

Jun 18, 2020

Appl. No.:

16/905178

Inventors:

- Cupertino CA, US
Kendall L. Helbert - San Francisco CA, US
Ari Y. Benbasat - San Jose CA, US
Clayton J. McCoy - San Francisco CA, US
Devon J. Rosner - Mountain View CA, US
Joshua A. Hoover - Saratoga CA, US
Sean M. Cole - San Jose CA, US
Yufei Zhao - Cupertino CA, US
Zhao Liu - Santa Clara CA, US
Judd Reed - Santa Rosa CA, US

International Classification:

G06F 3/044
G06F 3/041
H05K 5/03

Abstract:

An electronic device such as a portable electronic device may have display with a capacitive touch sensor. A cover may have a front portion and a rear portion that bend along a bend axis. The front portion may overlap the display when the cover is closed. Conductive structures such as a patterned conductive layer having elongated strips of conductive material separated by gaps or another predetermined pattern may be formed in the front portion of a cover or other portion of a cover that overlaps the display and capacitive touch sensor when the cover is closed. Control circuitry in the device can gather capacitance images with the touch sensor and can detect when the cover has transitioned from open to closed or from closed to open from whether the predetermined pattern becomes present or becomes absent in the capacitance images.

US Patent:

20190324574, Oct 24, 2019

Filed:

Apr 24, 2018

Appl. No.:

15/961742

Inventors:

- Cupertino CA, US
Kendall L. Helbert - San Francisco CA, US
Ari Y. Benbasat - San Jose CA, US
Clayton J. McCoy - San Francisco CA, US
Devon J. Rosner - Mountain View CA, US
Joshua A. Hoover - Saratoga CA, US
Sean M. Cole - San Jose CA, US
Yufei Zhao - Cupertino CA, US
Zhao Liu - Santa Clara CA, US
Judd Reed - Santa Rosa CA, US

International Classification:

G06F 3/044
H05K 5/03
G06F 3/041

Abstract:

An electronic device such as a portable electronic device may have display with a capacitive touch sensor. A cover may have a front portion and a rear portion that bend along a bend axis. The front portion may overlap the display when the cover is closed. Conductive structures such as a patterned conductive layer having elongated strips of conductive material separated by gaps or another predetermined pattern may be formed in the front portion of a cover or other portion of a cover that overlaps the display and capacitive touch sensor when the cover is closed. Control circuitry in the device can gather capacitance images with the touch sensor and can detect when the cover has transitioned from open to closed or from closed to open from whether the predetermined pattern becomes present or becomes absent in the capacitance images.
