Abstract:

A synchronizer eliminates metastability due to violation of either the setup time or the hold time of a circuit. The input of a first flip-flop () is tied to a constant logic level (VDD or ground). The first flip-flop receives an asynchronous signal into the reset (preset or clear) input of the flip-flop. No violation of the setup or hold times of the flip-flop can occur. The second flip-flop () receives the output of the first flip-flop as its clock input. The second flip-flop () is configured as a toggler. The second flip-flop produces a synchronized partial signal () of the original asynchronous signal (). Third and fourth flip-flops () may similarly be configured to produce a second synchronized partial signal () of the asynchronous signal recovery and may prevent runt pulses from being received by the flip-flops.
