Michael A Hunter

US Patent:

7431828, Oct 7, 2008

Filed:

Jul 6, 2005

Appl. No.:

11/174597

Inventors:

Michael G. Hunter - Orange CA, US
Rasmus G. Egeberg - Fredensborg, DK
Kim G. Knudsen - Hellerup, DK

Assignee:

Haldor Topsoe A/S - Lyngby

International Classification:

C10G 45/04
C07C 5/367

US Classification:

208212, 208209, 208213, 208 79, 208 95, 585252, 585411

Abstract:

A two-stage hydrotreating process is disclosed wherein a hydrocarbon stream is first desulphurized followed by a dehydrogenation step, which process comprises in combination contacting the feed and hydrogen over a hydrotreating catalyst at hydrotreating conditions, heating the hydrotreated effluent and hydrogen-rich gas from the hydrotreating reactor and contacting said effluent and hydrogen gas over a hydrotreating catalyst in a post-treatment reactor at a temperature sufficient to increase the polyaromatic hydrocarbon content and lower the hydrogen content of said effluent.

US Patent:

7763218, Jul 27, 2010

Filed:

Sep 26, 2005

Appl. No.:

11/234163

Inventors:

Michael Glenn Hunter - Orange CA, US
Angelica Hidalgo Vivas - Herlev, DK
Lars Skov Jensen - Lejre, DK
Gordon Gongngai Low - Tustin CA, US

Assignee:

Haldor Topsoe A/S - Lyngby

International Classification:

B01J 8/04
C10G 45/00
B01D 47/00
B01D 45/08

US Classification:

422191, 422188, 422190, 208 57, 208210, 208361, 96234, 55462, 55464, 55440, 55434

Abstract:

Partial conversion hydrocracking process comprising the steps of(a) hydrotreating a hydrocarbon feedstock with a hydrogen-rich gas to produce a hydrotreated effluent stream comprising a liquid/vapour mixture and separating the liquid/vapour mixture into a liquid phase and a vapour phase, and(b) separating the liquid phase into a controlled liquid portion and an excess liquid portion, and(c) combining the vapour phase with the excess liquid portion to form a vapour plus liquid portion, and(d) separating an FCC feed-containing fraction from the controlled liquid portion and simultaneously hydrocracking the vapour plus liquid portion to produce a diesel-containing fraction, orhydrocracking the controlled liquid portion to produce a diesel-containing fraction and simultaneously separating a FCC feed-containing fraction from the vapour plus liquid portion. The invention also includes an apparatus for carrying out the partial conversion hydrocracking process.

US Patent:

8002967, Aug 23, 2011

Filed:

Sep 12, 2006

Appl. No.:

12/067611

Inventors:

Michael Glenn Hunter - Orange CA, US
Angelica Hidalgo Vivas - Herlev, DK
Lars Skov Jensen - Lejre, DK
Gordon Gongngai Low - Tustin CA, US

Assignee:

Haldor Topsøe A/S - Lyngby

International Classification:

C10G 69/04
C10G 69/10

US Classification:

208 89, 208 57, 208 78, 208108, 208113, 208212, 208213

Abstract:

Partial conversion hydrocracking process comprising the steps of (a) hydrotreating a hydrocarbon feedstock with a hydrogenrich gas to produce a hydrotreated effluent stream comprising a liquid/vapor mixture and separating the liquid/vapor mixture into a liquid phase and a vapor phase, and (b) separating the liquid phase into a controlled liquid portion and an excess liquid portion, and (c) combining the vapor phase with the excess liquid portion to form a vapor plus liquid portion, and (d) separating an FCC feed-containing fraction from the controlled liquid portion and simultaneously hydrocracking the vapor plus liquid portion to produce a dieselcontaining fraction, or hydrocracking the controlled liquid portion to produce a diesel-containing fraction and simultaneously separating a FCC feed-containing fraction from the vapor plus liquid portion. The invention also includes an apparatus for carrying out the partial conversion hydrocracking process.

US Patent:

8333884, Dec 18, 2012

Filed:

Nov 23, 2009

Appl. No.:

12/624178

Inventors:

Michael Glenn Hunter - Orange CA, US
Angelica Hidalgo Vivas - Herlev, DK
Lars Skov Jensen - Lejre, DK
Gordon Gongngai Low - Tustin CA, US

Assignee:

Haldor Topsoe A/S - Lyngby

International Classification:

C10G 69/00

US Classification:

208 80, 208 89, 208108, 208113, 208212

Abstract:

Partial conversion hydrocracking process comprising the steps ofThe invention also includes an apparatus for carrying out the partial conversion hydrocracking process.

US Patent:

53586271, Oct 25, 1994

Filed:

Jan 31, 1992

Appl. No.:

7/828728

Inventors:

David E. Mears - Fullerton CA
Michael G. Hunter - Downey CA

Assignee:

Union Oil Company of California - Los Angeles CA

International Classification:

C10G 4508

US Classification:

208 59

Abstract:

High quality lubricating oil base stocks are produced from crude oils that contain significant concentrations of aromatic compounds in their higher boiling fractions. First, the crude is fractionated. After the residua fraction has been deasphalted, it is combined with the gas oil fraction. The resultant combined fraction is hydrocracked. The hydrocrackate is separated into a light fraction and a heavy fraction. The heavy fraction is hydrodewaxed, then hydrofinished. The hydrofinished product is combined with the light fraction and distilled into products including middle distillate fuel products and lubricating oil base stocks. The lubricating oil base stocks have high VI.

US Patent:

20200172818, Jun 4, 2020

Filed:

Aug 1, 2017

Appl. No.:

16/320421

Inventors:

- Kgs. Lyngby, DK
Michael Glenn HUNTER - Orange CA, US

Assignee:

Haldor Topsøe A/S - Kgs. Lyngby

International Classification:

C10G 67/14
B01D 3/14
B01D 3/38

Abstract:

A process including (a) directing a hydrocarbon mixture to contact a material catalytically active in hydrocracking under hydrocracking conditions, (b) providing a first hydrocracked product, (c) directing an amount of the first hydrocracked product and an amount of a converted hydrocracked product to a product separation step separating it into one or more products and a recycle oil having a higher boiling point than the products, (d) directing the recycle oil to contact a second material catalytically active in hydrocracking under hydrocracking conditions providing a second hydrocracked product, (e) directing at least an amount of the second hydrocracked product as feed to a second separation step, separating the second hydrocracked product in at least two fractions, a converted hydrocracked product and an unconverted oil an unconverted oil having a higher average boiling point than the recycle oil, (f) withdrawing at least an amount of the unconverted oil as purge.
